Routing IP VLAN/Interface Configuration
Use the Routing IP VLAN/Interface Configuration page to configure the IP routing settings for each
interface.
To display the page, click Routing > Configuration in the navigation pane and click the VLAN/Inter-
face Configuration tab.
Figure 80. Routing IP VLAN/Interface Configuration Page
Table 61. Routing IP VLAN/Interface Configuration Fields
Field Description
Type The type of interface that can be configured for routing:
 Interface – Enables list of all non-loopback interfaces that can be configured for routing.
 VLAN – Enables list of all VLANs that can be configured for routing.
VLAN The menu contains all VLANs that can be configured for routing. To configure routing settings
for a VLAN, select it from the menu and then configure the rest of the settings on the page.
Interface The menu contains all non-loopback interfaces that can be configured for routing. To
configure routing settings for an interface, select it from the menu and then configure the rest
of the settings on the page.
