Configuring ARP 131
ARP Table Statistics
Use this page to view information about the number and type of entries in the system ARP table. The
ARP table contains entries that map IP addresses to MAC addresses.
To display the ARP Table Statistics page, click Routing > ARP in the navigation pane, and then click
Statistics.
Figure 94. ARP Table Statistics Page
Table 71. ARP Table Statistics Fields
Field Description
Total Entry Count The total number of entries currently in the ARP table. The number includes both dynamically
learned entries and statically configured entries.
Peak Total Entries The highest value reached by the Total Entry Count. This value is reset whenever the ARP
table Cache Size configuration parameter is changed.
Active Static Entries The total number of active ARP entries in the ARP table that were statically configured. After
a static ARP entry is configured, it might not become active until certain other routing
configuration conditions are met.
Configured Static Entries The total number of static ARP entries that are currently in the ARP table. This number
includes static ARP entries that are not active.
Maximum Static Entries The maximum number of static ARP entries that can be configured in the ARP table.
