Port Configuration 39
Port Summary Statistics
The Port Summary Statistics page displays statistics on packets transmitted and received on each port
or trunk. These statistics can be used to identify potential problems with the switch. The displayed val-
ues are the accumulated totals since the last clear operation.
To display the Port Summary Statistics page, click Switching > Port Configuration in the navigation
pane and select the Statistics tab.
Figure 18. Port Summary Statistics Page
Table 12. Port Summary Statistics Fields
Click Clear All Counters to reset all statistics to zero.
Field Description
Interface The port or trunk ID.
Received Packets w/o Error The count of packets received on the port without any packet errors.
Received Packets with Error The count of packets received on the port with errors.
Broadcast Received Packets The count of broadcast packets received on the port.
Transmitted Packets w/o Error The number of packets transmitted out of that port without any packet errors.
Transmitted Packets with Error The number of packets transmitted out of the port with packet errors.
Collisions The number of packet collisions.
Transmitted Pause Frames The number of Ethernet pause frames transmitted. (This information is collected for ports
but not for trunks.)
Received Pause Frames The number of Ethernet pause frames received. (This information is collected for ports
but not for trunks.)
