Page 172 Port Access Control
Port Access Control Statistics
Use this page to view information about the Extensible Authentication Protocol over LAN (EAPOL)
frames and EAP messages sent and received by the local interfaces. To view additional per-interface
EAPOL and EAP message statistics, select the interface with the information to view and click Details.
To access the Port Access Control Statistics page, click Security > Port Access Control in the navi-
gation pane, and click the Statistics tab.
Figure 124. Port Access Control Statistics Page
Table 93. Port Access Control Statistics Fields
Field Description
Interface The interface associated with the rest of the data in the row. When viewing detailed
information for an interface, this field identifies the interface being viewed.
PAE Capabilities The Port Access Entity (PAE) role, which is one of the following:
Authenticator – The port enforces authentication and passes authentication informa-
tion from a remote supplicant (similar to a client or host) to the authentication server. If
the server successfully authenticates the supplicant, the port allows access.
Supplicant – The port must be granted permission by the authentication server before
it can access the remote authenticator port.
EAPOL Frames Received The total number of valid EAPOL frames received on the interface.
EAPOL Frames Transmitted The total number of valid EAPOL frames sent by the interface.
Last EAPOL Frame Version The protocol version number attached to the most recently received EAPOL frame.
Last EAPOL Frame Source The protocol version number attached to the most recently received EAPOL frame.
