LLDP-MED Global Configuration 97
The following information displays for each port:
Table 48. LLDP Global Configuration—Port Fields
To enable or disable LLDP-MED on one or more interfaces, and to configure related features, select
the interfaces and click Edit.
Figure 67. Edit LLDP-MED Interface
To modify settings on all interfaces, click Edit All. The settings you configure are applied to all inter-
faces.
Field Description
Interface The ID of the physical and trunk interfaces.
Link Status The link status of the interface, which is either Up or Down. An interface that is down does not
forward traffic.
MED Mode The administrative status of LLDP-MED on the interface. When enabled, the LLDP-MED
transmit and receive functions are effectively enabled on the interface. This feature is enabled
by default.
Notification Status Indicates whether LLDP-MED topology change notifications are enabled or disabled on the
interface. This feature is disabled by default.
Operational Status Indicates whether the interface is configured to transmit TLVs. To transmit TLVs, the interface
must be enabled to receive and transmit LLDPDUs and must be connected to an LLDP-MED
device. The switch waits for the LLDP-MED device to advertise its information before the
switch transmits its own LLDP-MED TLVs, at which point the operational status becomes
enabled.
Transmitted TLVs The LLDP-MED TLV(s) that the interface transmits. The HPE OfficeConnect 1920S switch,
can transmit TLVs of the following types:
Capabilities
Network Policy
