HT2000H_en_n.doc Page 33 of 167
Warning
If necessary, it is possible to move the turret and needle motors by hand, very carefully, but only
when the autosampler is switched off. Rapid movements or movements with the autosampler
switched on can damage the autosampler.
2.3 Tool kit
The autosampler is provided with a tool kit containing:
1. Syringe pointer that may be used for the syringe installation (see paragraph 4.2.2
“
Setup: Syringe warmer assembly installation
”) and for locking/unlocking the au-
tosampler from the mounting kit (see paragraphs 3.3.1 “Autosampler installation on the
mounting plate” and 3.3.1.1 “Unlock the autosampler from the mounting kit”).
Figure 24: Syringe pointer
2. Allen key (2.5mm) that it is used for syringe replacement (see paragraph 9.1.5 “Syringe
replacement in the syringe warmer assembly”):
Figure 25: Allen key
With some accessories (spacers kit) these tools are provided:
1. Tweezers type 1 used to extract the relative spacer:
