HTA HT2000H - Start-Up; Pc Connection and Software Installation

HT2000H_en_n.doc Page 56 of 167
3.4 Start-Up
The main power switch is on the back of the autosampler (see Figure 22, switch 1), switch it ON (“I”
position).
When the autosampler (HT2000H/HT2000HT versions) is switched on a program loading screen
appears (see paragraph 2.4.2 “Screen templates “). Then the displays shows the autosampler firmware
release.
After the program has loaded the display shows the “HOME SCREEN” (see paragraph 7.1 “Home
screen”).
During the start up process, the autosampler will proceed to check the incubation oven.
For HT2000H/HT2000HT, if the oven is not empty, a screen appears asking if the oven has to be
unloaded. If so, a following screen asks where to move the vial(s).
For HT2100H, if the single position oven is not empty, the autosampler moves the vial automatically
from the oven to position 14 of the sample rack (see paragraph 2.1.2.2 “HT2100H Sample rack”). If this
position is also busy the 4 status LED will blink. Please connect “HTA Autosampler Manager” and
access the virtual screen. A screen asks where to move the vial.
Warning
The virtual screen is available only with LAN connection. It is not available with RS232 connection.
3.5 PC connection and software installation
“HTA Autosampler Manager” software is required for the use of HT2100H, it is optional for the
HT2000H/HT2000HT.
Warning
HTA Autosampler Manager comes in two versions: Standard version and CFR 21 Part 11
version. In the document in which is reported the Activation key you will find information about
the version for which you have been granted a license.
