In order to set the regulating lock, please proceed as follows:
Warning
If you don’t adjust the safety lock, after start up the autosampler will display an error message
(see paragraph 8 “Troubleshooting“). For an accurate first installation, do not release the
needle guide regulator – right block (see paragraph 4.2.2 “Setup: Syringe
warmer assembly installation“).
1. Open the Syringe location by pushing up the sliding lid (see Figure 15).
2. Lift down the sledge manually (see Figure 54 and Figure 54) till the left block become
visible (see Figure 57).
3. Loosen the left block (safety lock) using the supplied syringe pointer (see Figure 24) as
shown in Figure 57.
4. Let the right block move down until it rests on the sledge.
5. Lift the left block about 2-3mm above the right block level and lock it.
6. Verify that the vial locator can be lifted freely by hand. If not, verify that the right and left
block are locked parallel.
7. Close the sliding lid.
3.3.3 Electrical connections
Warning
Check that the autosampler is switched OFF.
Do not use a power supply system different from the one supplied with this unit. This could
cause damage to the autosampler or to the person using it.
Proceed as follows:
1. Connect the analyzer to its connector (number 5 in Figure 22) (15 pin port) using the
interface cable provided with the mounting kit.
