HTA HT2000H - Installation; Autosampler Installation on the Mounting Plate

HT2000H_en_n.doc Page 48 of 167
Figure 48: How to lift and carry the autosampler
3.3 Installation
Please read this chapter before using the autosampler . To install the autosampler follow the instructions
below.
HT2000H/HT2000HT installation operations should be performed using the touch screen display.
HT2100H installation operations should be performed only by using a PC, through the software “HTA
Autosampler Manager”; this has the same screens described below for the HT2000H/HT2000HT.
1. Install the autosampler on the mounting plate (see paragraph 3.3.1 “Autosampler installation on
the mounting plate”).
2. Move the safety lock from the shipping position to the operating position (see paragraph
3.3.2 “Safety Lock setting”);
3. Connect cables (see paragraph 3.3.3 “Electrical connections”).
4. Connect purge line (see paragraph 3.3.4 “Purge line connections”);
5. Switch on the autosampler (see paragraph 3.4 “Start-Up”);
6. Install PC software (see paragraph 3.5 “PC connection and software installation“) (This operation
is mandatory for HT2100H, and optional for HT2000H/HT2000HT).
7. Install the syringe (see paragraph 4.2.2 “Setup: Syringe warmer assembly installation”).
8. Select the analyzer (see paragraph 4.2.1.1 “Alignment: Analyzer Default”).
9. Align the autosampler on the GC Injector(s) (see paragraphs 4.2.1.2 “Alignment: Front Injector”
and 4.2.1.3 “Alignment: Rear Injector“).
10. For HT2000H/HT2000HT only. Install the sample rack(s) (see paragraph 7.6.1 “Change tray/rack
type”).
11. Perform the touch and plunger zero procedure (see paragraph 4.2.1.4 “Alignment: Touch Plunger
Zero”).
12. Finish the installation (see paragraph 3.9 “Basic training”).
3.3.1 Autosampler installation on the mounting plate
Warning
Follow the instructions with the autosampler switched off. Moving the unit with the autosampler
switched ON can cause serious damage to the autosampler.
