Figure 10-3 Removing the rear drive module
Step 7 Take a spare battery out of its ESD bag.
Step 8 Hold the battery with the side marked with text facing upwards, insert the left end of the
battery into the slot, and gently press down the battery until it is properly installed in the slot.
See Figure 10-4.
TaiShan 2280 V2 Server
User Guide
10 Battery
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 135
