l Host Name (or IP address): Enter the IP address of the server to be accessed, for
example, 191.100.34.32.
l Port: Retain the default value 22.
l Connection type: Retain the default value SSH.
l Close window on exit: Retain the default value Only on clean exit.
NOTE
Configure Host Name (or IP address) and Saved Sessions, and click Save. You can double-click the
saved record under Saved Sessions to log in to the server the next time.
Step 5 Click Open.
The PuTTY window is displayed.
NOTE
If this is your first login to the server, the PuTTY Security Alert dialog box is displayed. Click Yes to
proceed.
If an incorrect user name or password is entered, you must set up a new PuTTY session.
Step 6 Enter the user name and password.
If the login is successful, the server host name is displayed on the left of the prompt.
----End
TaiShan 2280 V2 Server
User Guide
14 Common Operations
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 161
