Hypertherm XPR300 Replacement Part Procedures

Parts List
5
XPR300 Instruction Manual 809970 135
Part number Description Quantity
1 229792 Manifold: Gas input (no adapters) 1
2 104843 Manifold: Gas output (no adapters) 1
3 229844 Water regulator 1
4 006157 Check valve 1
Push-to-connect adapters
5 015905 1/8 inch NPT X 1/4 inch tube 2
6 015910 3/8 inch NPT X 5/16 inch tube 2
7 015907 1/4 inch NPT X 3/8 inch tube 1
8 015876 1/4 inch NPT X 1/4 inch tube 1
9 015853 Elbow: 1/4 inch NPT X 5/16 inch tube, 90° 1
10 015909 Elbow: 3/8 inch NPT X 5/16 inch tube, 90° –
Threaded adapters with thread sealant applied
11 015103 1/4 inch NPT X RH ‘B’ inert female 3
12 015012 1/4 inch NPT X #6 male 3
13 015009 1/4 inch NPT X RH ‘B’ male 1
14 015922 1/4 inch X hexagonal collar 2
15 015230 1/4 inch NPT X LH ‘B’ 1
16 015116 Adapter: 1/8 inch NPT X RH ‘A’ (oxygen outlet) 1
17 015210 Adapter: 1/8 inch NPT X LH ‘A’ male (hydrogen mix outlet) 1
18 015197 Adapter: 1/8 inch NPT X #5 male (argon outlet) 1
