Draft Document for Review October 18, 2004 5486SSum.fm

Chapter 5. Summary of today’s iSeries

The tables in this chapter summarize the resource capabilities and performance

characteristics of all processors in the current product line of iSeries servers.

Processor and performance characteristics are included, along with the

maximum capacities for main storage, disk, local area network (LAN),

communication lines, workstations, tape devices, CD devices, and other

input/output (I/O) components.

The following graphic depicts the CPW ratings of each of the currently marketed

IBM Eserver i5 servers.
