5486IOA.fm Draft Document for Review October 18, 2004
360 IBM Eserver i5 and iSeries System Handbook
#4811/#4812/#4813/9812/#9813 PCI-X Integrated xSeries Server
The #4811/#4812/#4813/9812/#9813 PCI-X Integrated xSeries Server contains
an Imntel Pentium 2.0GHz processor with 2MB integrated L2 cache. Features
#4811, #4812, #4813 are functionally identical but have some physical
differences depending on the model in which they are used.
The #4811 is supported in the 520 system tower. The #4812 is supported in the
550, 595, 800, 810, 825, 870 and 890 system towers and in the #0588, #0595,
#5088, #5095, #5074, #5079, #5094 and #5294 expansion towers. The #4813 is
supported in the 570 system tower and in the 5790 expansion unit.
The #9812 and #9813 are functionally identical to #4812 and #4813 but are
included in the base with orders for Enterprise Editions on system models 550,
595 and 570
The #4811/#4812/#4813/9812/#9813 PCI-X Integrated xSeries Server has two
memory slots and supports up to 2GB of memory. Both slots must always
contain a pair of identical memory features. When
#4811/#4812/#4813/9812/#9813 is ordered, the eServer Marketing Configurator
adds two #9726 base 512MB server memory features to the order. The two
#9726 features may be replaced with two #8546 optional base 1GB server
memory features.
The following main storage cards provide memory for the
#4811/#4812/#4813/9812/#9813 PCI-X Integrated xSeries Server:
#0446 - 512MB DDR Server Memory. Available with an upgrade only.
#0447 - 1GB DDR Server Memory. Available with an upgrade only.
#9726 - Base 512MB Server Memory. Available with the initial order only.
#8546 - Opt Base 1GB Server Memory. Available with the initial order only
The #4811/#4812/#4813/9812/#9813 PCI-X Integrated xSeries Server occupies
two PCI slots and requires an IOP #9744, #9844 or #2844 to drive it. The
eServer Marketing Configurator will add no charge feature #9744 Base PCI IOP
to the order, however the #9744 may be removed from the order for PCI slot
conservation. The IOP may be shared, but only one
#4811/#4812/#4813/9812/#9813 is permitted per IOP.
Placement of the PCI-X Integrated xSeries Server is limited to specific slots.
Placement of the #4811 is limited to slot P1-C4 on the model 520 system unit.
The #4811 hangs over slot P1-C5 and occupies two PCI slots.
Placement of #4812/#9812 is limited to specific PCI slots within the i550, 595,
800, 810, 825, 870 and 890 system towers and the various expansion towers.
Placement of the #4813/#9813 is limited to specific PCI slots within the 570
system model and #5790 expansion unit.
