iSeries Model 520 117
Draft Document for Review October 18, 2004 5486m520.fm
The Model 520 initial installation is Customer Setup (CSU). IBM Service
Representatives perform the processor upgrades within models.
Processor features
#8950 Model 520 Processor (POWER5 1.5 GHz Uni CCIN 522A)
– Eight Dual Inline Memory Module (DIMM) memory positions (plug directly
onto the processor, direct attach)
– No L3 cache
– #7450 Processor Capacity Card (CCIN 7450) required with this processor
feature
#8951 Model 520 Processor (POWER5 1.5 GHz Uni CCIN 522A)
– Eight DIMM memory positions (plug directly onto the processor, direct
attach)
– No L3 cache
– #7451 Processor Capacity Card (CCIN 7451) required with this processor
feature
#8952 Model 520 Processor (POWER5 1.5 GHz Uni CCIN 522A)
– Eight DIMM memory positions (plug directly onto the processor, direct
attach)
– No L3 cache
– #7458 or #7459 Processor Capacity Card (CCIN 7458/7459) required with
this processor feature
#8953 Model 520 Processor (POWER5 1.5G Hz Uni CCIN 522A)
– Eight DIMM memory positions (plug directly onto the processor, direct
attach)
– No L3 cache
– #7452 or #7453 Processor Capacity Card (CCIN 7452/7453) required with
this processor feature
Note: A #1827 Serial-UPS conversion cable is required to provide UPS
control/feedback information for the Eserver i5 Model 520. This does not
impact the ability of the UPS to provide power in case of an outage. Its
absence prevents the UPS from alerting the Model 520 that it is under UPS
power and from advising the server to the amount of remaining UPS
battery power.
