iSeries Model 570 145
Draft Document for Review October 18, 2004 5486m570.fm
– #5548 System Console on 100 Mbps Ethernet
• #2849 10/100 Mbps Ethernet Adapter
• #0367 Operations Console PCI Cable
– #5550 System Console on HMC
The HMC is required for systems using logical partition (LPAR), IBM
Eserver Capacity Upgrade on Demand (CoD), concurrent maintenance
and upgrade operations, and redundant Service Processor operations.
Optional features
The optional features for the 570 system unit include:
#1800 HSL-2 Ports - 2 Copper
Adds capacity for second HSL-2/RIO-G loop
#1801 Optical Bus Expansion Card - 2 port
Adds capacity for an optical HSL loop
#7875 Redundant CPU Regulator
Uninterruptible power supply
An external uninterruptible power supply is recommended to protect the
system unit and any external components against utility power outages.
The Model 570 initial installation is IBM installed. Processor upgrades within
models are performed by IBM Service Representatives.
Processor features
The #8961 Processor (POWER5, 0/2-way, 1.65Ghz, CCIN 26EA)(withdrawn
from marketing 10/04) include:
– 36 MB L3 cache per processor card
– 1.88 MB L2 cache chip
Note: A #1827 Serial-UPS conversion cable is required to provide UPS
control/feedback information for the Eserver i5 Model 570. This does not
impact the ability of the UPS to provide power in case of an outage. Its
absence prevents the UPS from alerting the Model 570 that it is under UPS
power and from advising the server to the amount of remaining UPS
battery power.
