iSeries I/O processors 331
Draft Document for Review October 18, 2004 5486IOp.fm
A #0325 IPCS Extension Cable for Windows is the default (but may be
removed).
A minimum of 128 MB server memory is required.
The #1700 IPCS Keyboard or Mouse for Windows is the default (in those
countries (regions) that offer it).
A display must be connected to the Integrated xSeries Server to support
Windows.
For a non-U.S.A. keyboard or mouse and display, see:
http://www.iseries.ibm.com/windowsintegration
The #2799 and #2899 PCI Integrated xSeries Server require OS/400 V5R1 (with
program temporary fixes (PTFs)) or later. For required PTF information, see
Informational APAR II13105 at:
http://www-912.ibm.com/n_dir/nas4apar.nsf/nas4aparhome
The #2799 was
withdrawn from marketing on 21 November 2003.
#4710/#4810/#9710 PCI Integrated xSeries Server
The #4710, #4810, or #9710 has a 2 GHz processor and four memory slots.
Each server memory slot can contain one of the following features, providing a
total main storage capacity from 1,024 MB to 4,096 MB:
512 MB server memory (#0426/#9726)
1 GB server memory (#0427)
A minimum of two server memory cards are required and must be installed in
identical capacity pairs. On model upgrades or MES orders, you may order a
#4710/#4810 without memory features if usable supported memory features
already exist on the installed system.
The #4710, #4810, or #9710 includes one embedded 100/10 Mbps Ethernet LAN
controller. It can support the following LAN IOAs in combination:
#2744 PCI 100 Mbps Token Ring IOA
#5700 PCI 1 Gbps Ethernet IOA
#5701 PCI 1 Gbps Ethernet UTP IOA
You can order the #4710/#4810 without any LAN IOA features.
When a LAN feature is used in conjunction with a #4710, the following ordering
rules apply:
