Table 3: Summary of the iSeries Model 570, part 1
Model 570
Processor feature
#8961 #8961 (x2)
Server feature
#0919 #0920
Relative system performance
1, 5a
Processor CPW 3300/6000 6350/12000
Mail and Calendar Users
9
7300/13300 14100/25900
5250 CPW
5
Number of i5/OS Licenses
Standard 0 0
Enterprise Maximum Maximum
High Availability
Capacity BackUp
Number/type/speed of processor 0/2/POWER5/1.65 GHz 2/4/POWER5/1.65 GHz
L2 Cache (MB) per processor (SCM) 1.88 1.88
L3 Cache (MB) per processor (SCM) 36 36
Main storage (GB minimum/maximum) 2/32 2/64
Main storage DIMMs (minimum/maximum) 4/8 8/16
Logical partitions (LPAR) 10/20 20/40
Minimum i5/OS level
8
V5R3 V5R3
Software group
6b
P30 P30
Disk storage (GB)
Integrated minimum 35.16 35.16
Integrated maximum 19474.56 38525.76
External maximum
7
19439.40 38490.60
Total maximum 19474.56 38525.76
DASD arms maximum 276 546
Internal arms 276 546
External LUNs 275 545
Physical packaging
Rack design - EIA units 4 4
External HSL-2/RIO-G ports 2 4
External HSL-2/RIO-G loops 1 2
PCI/PCI-X Expansion Tower 6 12
External xSeries Servers (IXA) 8 16
PCI card slots
12
90 173
Diskette drive (8” or 5-1/4”) 0 0
Communication lines
3
278 320
LAN ports (includes embedded) 71 96
Integrated xSeries Servers 18 36
Twinaxial workstation controllers 69 134
Twinaxial workstations 2760 5360
Internal DVD-ROM/DVD-RAM
7a
11
Internal CD-ROM/Tape 0 0
Feature I/O Tower CD-ROM/Tape 12 24
External tape / LPAR 18/36 18/36
External optical/CD/DVD 18/36 18/36
