5486Up8x.fm Draft Document for Review October 18, 2004
316 IBM Eserver i5 and iSeries System Handbook
Upgrade options for expansion towers
Converting the #5065, #5066, and #5075 PCI Expansion Tower allows you to
upgrade to newer, faster, and higher function HSL-attached I/O towers.
Conversions are available for:
#5065 Storage/PCI Expansion Tower to #5074 PCI Expansion Tower
#5066 1.8 M I/O Tower to #5079 1.8 M I/O Tower
#5075 PCI Expansion Tower to #5074 PCI Expansion Tower
While most features from the expansion towers are supported in the new towers,
many require no-charge feature conversions because the feature number is
different in the new tower. Those features not supported in the new towers must
be re-installed in the system unit or replaced with a new feature.
The no-charge feature conversions in the following table are available to move
features from the #5065/#5066 towers to PCI or PCI-X towers and expansion
units in iSeries Models 520, 550, 570, 595, 810, 820, 825, 830, 840, 870, and
890.
The converted features are physically and functionally identical.
The #5065/#5066 features listed in the following table are not supported in the
#5074/#5079 towers. They must be replaced.
From feature To feature From feature To feature
#2723 #4723 #9723 #4723
#2745 #4745 #2746 #4746
#2748 #4748 #2750 #4750
#2751 #4751 #2761 #4761
#4748 #4778 #2815 #4815
#2816 #4816 #2818 #4818
#2838 #4838 #4802 #4801
Note: The feature numbers and some names change to designate installation
information.
From feature Suggested replacement feature
#2718 PCI Magnetic Media Controller #2768 PCI Magnetic Media Controller
