5486MSum.fm Draft Document for Review October 18, 2004

804 IBM Eserver i5 and iSeries System Handbook

9406 Model 720

Model 720

Processor feature #2061 #2062 #2063 #2064

Relative system performance

Version 4 Release 3 and later

Processor CPW

240 420 810 1600

Interactive CPW/system feature code

#1500 (Base)

#1501

#1502

#1503

#1504

#1505

35/206A

70/206B

120/206C

35/206D

70/206E

120/206F

240/207A

35/207B

120/207C

240/207D

560/207E

35/207F

120/208A

240/208B

560/208C

1050/208D

Number of processors 1 1 2 4

Main storage (MB) 256-2048 256-4096 256-8192 256-8192

Software group

P10-P20 P10-P20 P20-P30 P20-P30
