iSeries Model 870 227
Draft Document for Review October 18, 2004 5486m870.fm
A bus adapter is included to provide the HSL interface to the top enclosure.
Select one of the following types:
#9886 - Base Optical Bus Adapter, to specify four optical HSL ports
#9887 Base HSL-2 Bus Adapter, to specify four copper HSL-2 ports
Three or four cables must be ordered to attach to the HSL or HSL-2 ports. When
ordering cables to connect to the HSL interface, optical HSL, copper HSL, copper
HSL-2, or copper HSL to HSL-2 cables are required. An HSL loop uses all optical
or all copper ports and cables. A copper loop can intermix I/O towers and units
with copper HSL and copper HSL-2 ports. Select the appropriate cable based on
the type of HSL ports to which it is being attached and the cable length required.
Specify three or four line cords for the #8094 Optional 1.8 M I/O Rack.
If the top enclosure is to be attached to a different system than what was initially
ordered, remove for Record Purpose Only (RPO) the #0694 - #5094 Equivalent
specify code from the initially ordered system and add it to the target system.
A schematic of the #8094 Optional 1.8 M I/O Rack can be found on page 248.
#5114 Dual Line Cords - Tower
The required #5114 feature provides dual line cord support for the #9094 Base
PCI I/O Enclosure on the Model 870 and 890 and for the lower enclosures of the
#8093 and #8094 towers. With the #5114, the enclosure requires two #14xx line
cords and has two AC input boxes.
9406 Model 870 schematics
The following diagrams show slot and feature card arrangement of the Model 870
system unit, base enclosure, and rack. You can find schematics of any supported
expansion units in Chapter 15, “Towers, racks, and high-speed link” on page 259.
