iSeries Model 800 187
Draft Document for Review October 18, 2004 5486m800.fm
Refer to “Table 6: Summary of the iSeries Model 800” on page 95, to find
Processor CPW, Mail and Calendar Users (MCU), 5250 CPW, and to determine
the processor feature code and QPRCFEAT value.
Main storage
Supported memory features for the Model 800 are:
#3092 - 256 MB Main Storage (DIMM DDR 128 Mb technology)
#3093 - 512 MB Main Storage (DIMM DDR 256 Mb technology)
#3094 - 1 GB Main Storage (DIMM DDR 256 Mb technology)
#3096 - 2 GB Main Storage (DIMM DDR 256 Mb technology)
Configuration considerations for memory include:
A single main storage DIMM is allowed.
When additional memory is required, the existing memory card must be
paired with a card of similar capacity. Additional DIMMs must be added in
pairs of the same capacity and technology.
Eight slots are available in the base system for main storage DIMMs, which
plug directly onto the backplane.
The #0864 and #0865 Server features require a minimum of 512 MB.
The following table shows the allowable main storage capacities in MB for the
Model 800 processors.
9406 Model 800 schematics
The following diagrams show the slot and feature card arrangement of the Model
800 system unit, processor, memory cards, and supported expansion units.
256
*
512
*
1024 1536
2048 2560 3072 3584
4096 4608 5120 5632
6144 6656 7168 7680
8192
* The #0864 and #0865 Server features require a minimum of 512 MB.
