164 IBM Eserver i5 and iSeries System Handbook
– #4317 8.58 GB 10k RPM Disk Unit **
– #4318 17.54 GB 10k RPM Disk Unit **
– #4319 35.16 GB 10k RPM Disk Unit
– #4326 35.16 GB 15k RPM Disk Unit
– #4327 70.56 GB 15k RPM Disk Unit
One of the following load source specify codes is required:
– #0829 - #4318 Load Source Specify *
– #0830 - #4319 Load Source Specify *
– #0834 - #4326 Load Source Specify
– #0835 - #4327 Load Source Specify
򐂰 Disk protection specify codes (one must be specified)
– #0040 Mirrored System Disk Level
– #0041 RAID Protection - All
– #0042 Mirrored System IOP Level
– #0043 Mirrored System Bus Level
#0042 is the default for disk data protection.
򐂰 System console/communications adapter
The console on LAN options requires a dedicated LAN adapter.
– #5540 System Console on Twinaxial Workstation IOA
• #4746 PCI Twinaxial IOA
– #5544 System Console on Operations Console
• #0367 Operations Console PCI Cable
– #5546 System Console on 100 Mbps Token Ring
• #2744 PCI 100 Mbps Token Ring IOA
• #0367 Operations Console PCI Cable
– #5548 System Console on 100 Mbps Ethernet
• #0367 Operations Console PCI Cable
• #2849 10/100 Mbps Ethernet Adapter or
• #4838 PCI 100/10 Mbps Ethernet IOA
– #5550 System Console on HMC
An #0367 Operations Console PCI Cable is added to the order by the IBM
marketing configurator.
Optional features
The optional features for the i5 Model 595 include the following internal tape
devices:
