#9844 Base PCI IOP provides support for:
– The required SCSI IOA which controls up to 15 disk units, the required
DVD-RAM/DVD-ROM, and an internal tape feature or a
DVD-RAM/DVD-ROM feature
– A base Console/Workstation IOA
The IBM marketing configurator determines which feature combinations
are placed on the order based on the #5540, #5544, #5546, #5548 or
#5550 System Console specify code.
– The #9771/#9793/#9794 Base PCI Two-Line WAN with integrated modem
Two Service Processors (CCIN 28DE). Each contains:
– One SPCN (RS485) control for attached I/O subsystems
– Two ethernet ports for connection to HMC through Bulk Power Controller
– Two ports for connection to Front and Rear Light Strips
Anchor card
The Anchor card is considered part of the base system unit hardware.
Required features
The required features for the 595 system unit include:
Supported specific combinations of the Processor feature, Edition feature,
and Server feature, as shown in the following table.
Note: A Hardware Management Console (HMC) is required to manage
specific configurations. See “Hardware Management Console” on
page 742 for more information.
Note: The features listed in this section that are not orderable as new features
are marked as follows:
* Supported as migration feature only
** Supported in system unit for upgrades only
*** Miscellaneous Equipment Specification (MES) only
