5486SSum.fm Draft Document for Review October 18, 2004

86 IBM Eserver i5 and iSeries System Handbook

Table 2: Summary of the iSeries Model 550

Model 550

Processor feature

#8958

Server feature

#0915

Relative system performance

1, 5a

Processor CPW 3300/12000

Mail and Calendar Users

7300/?26600

5250 CPW

#7462 Standard 0

#7463 Enterprise Maximum

Number/type/speed of processor 1/4/POWER5/1.65 GHz

L2 Cache (MB)/ chip 1.88

L3 Cache (MB)/ processor card 36

Main storage (GB min/max) 2/64

Main storage DIMMs (minimum/maximum) 4/16

Logical Partitions (LPAR) 40

Minimum operating system level V5R3

Software group

P20

Default Chapter1
