#5114 Dual Line Cords - Tower
The #5114 required feature provides dual line cord support for the #9094 Base
PCI I/O Enclosure on the Model 870 and 890 and for the lower enclosures of the
#8093 and #8094 towers. With the #5114, the enclosure requires two #14xx line
cords and has two AC input boxes.
9406 Model 890 schematics
The following diagrams show the slot and feature card arrangement of the Model
890 system unit, base enclosure, and rack. Chapter 15, “Towers, racks, and
high-speed link” on page 259, shows the schematics of any supported expansion
units.
