iSeries Model 800 185
Draft Document for Review October 18, 2004 5486m800.fm
Optional features
The optional features include:
Internal tape device
– #4582 4 GB ¼-inch Cartridge Tape Device
– #4584 30 GB ¼-inch Cartridge Tape Device
– #4585 80 GB VXA-2 Tape Device
– #4587 50 GB ¼-inch Cartridge Tape Device
– #8287 Opt Base 50 GB ¼-inch Cartridge Tape Device
– #9284 30 GB ¼-inch Cartridge Tape Device
– #9285 Base 80 GB VXA-2 Tape Device
#0551 iSeries Rack
– Up to two Model 800s may be installed in an #0551 rack.
– Any Model 800 mounted in an #0551 must have the #7116 System Unit
Expansion.
– Specify codes and features supported when used in conjunction with a
Model 800 include the #0133 Plant Install in Rack and #0137 Field Install
in Rack.
See “#0551 iSeries Rack” on page 285 for a complete description of the
#0551 iSeries Rack and supported features and specify codes.
#7002 HSL Enabler
– The #7002 is an high-speed link (HSL) internal flex cable, which enables
HSL capability to allow connection to one PCI or PCI-X expansion tower.
– This cable connects the processor with a right angle bus connector to the
back of the machine. Two HSL cables (#14XX) are required to connect the
CEC to the expansion tower.
#7116 System Unit Expansion
– System unit expansion supports up to an additional 12 disk units.
– The #7116 has no PCI card slots and no removable media slots.
– Supports six disk units.
– Disk units are driven by up to two disk unit controllers located in the CEC.
– A #7137 DASD Concurrent Maintenance Cage is required.
– A #7136 DASD Expansion Unit - 6 slot is required to support more than six
disk units.
– Requires a separate power cord.
– If installed in an #0551 iSeries Rack, it may be powered by a PDU by
ordering #1422 PDU Line Cord.
