Table 4: Summary of the iSeries Model 570, part 2Table 4a:
Model 570
Processor feature
#8971 #8971 #8971 #8971 #8971 #8971
Server feature
#0930 #0921 #0922 #0924 #0926 #0928
Relative system
performance
1, 5a
Processor CPW 3300/
6000
6350/
12000
15200/
23650
25500/
33400
36300/
44700
6350/
44700
Mail and Calendar
Users
9
7300/
13300
14100/
26600
33600/
52500
57300
77000
83600/
102000
14100/
102000
5250 CPW
5
Standard 00000
Enterprise Maximum Maximum Maximum Maximum Maximum
High Availability Maximum Maximum Maximum Maximum Maximum
Capacity BackUp Maximum
Number/
type/
speed of processor
1/2/
POWER5/
1.65 GHz
2/4/
POWER5/
1.65 GHz
5/8/
POWER5/
1.65 GHz
9/12/
POWER5/
1.65 GHz
13/16/
POWER5/
1.65 GHz
2/16/
POWER5/
1.65 GHz
L2 Cache (MB)/chip 1.88 1.88 1.88 1.88 1.88 1.88
L3 Cache (MB)/processor
card
36 36 36 36 36 36
Main storage (GB
minimum/maximum)
2/64 4/128 8/256 12/384 16/512 16/512
Main storage DIMMs
(minimum/maximum)
4/8 8/16 16/32 24/48 32/64 32/64
Logical partitions (LPAR) 10/20 20/40 50/80 90/120 120/160 20/160
Minimum i5/OS level
8
V5R3 V5R3 V5R3 V5R3 V5R3 V5R3
Software group
6b
P30 P30 P40 P40 P40 P30
Disk storage (GB)
Integrated minimum 35.16 35.16 35.16 35.16 35.16 35.16
Integrated maximum 19474.56 38525.76 5800.32 77474.88 96949.44 96949.44
External maximum
7
19439.40 38490.60 57929.76 77404.32 96878.88 96878.88
Total maximum 19474.56 38525.76 5800.32 77474.88 96949.44 96949.44
DASD arms maximum 276 546 822 1098 1374 1374
Internal arms 276 546 822 1098 1374 1374
External LUNs 275 545 821 1097 1373 1373
Physical packaging
