5486SSum.fm Draft Document for Review October 18, 2004

104 IBM Eserver i5 and iSeries System Handbook

Numbers are for all 890 processor features #9094

Base Tower

System maximum

Disk storage (GB)

Integrated minimum 17.5

Integrated maximum 3175.2 144446

External maximum

11290 144375

Total maximum 14462 144446

DASD arms maximum

Arms internal 45 2047

LUNs external 160 2046

Physical packaging

External HSL/HSL-2 ports -/24 -/24

External HSL/HSL-2 loops -/12 -/12

PCI/PCI-X Expansion Towers 47 47

External xSeries Servers 60 60

Embedded IOP - -

Embedded IOA - -

PCI card slots 14 672

Maximum PCI IOA cards

11 528

Diskette drive (8” or 5-1/4”) 0 0

Communication lines

38 480

LAN ports 7 128

Integrated xSeries Servers 2 48

Twinaxial workstation controllers 9 180

Twinaxial workstations 360 7200

Internal CD-ROM/DVD-RAM/tape

226

External tape/optical/CD/DVD 9 26

Cryptographic coprocessor 8 32

Cryptographic accelerator 4 8
