5486m570.fm Draft Document for Review October 18, 2004
148 IBM Eserver i5 and iSeries System Handbook
Memory Minimums: Each processor card must have at least one set of
memory DIMM placed on it. As memory is in features codes of quads. The
following memory minimums have been established:
Balancing: Each 0/2 way processor card must have a minimum of 2 GB
memory on it.
Spreading: Memory should be spread across the processor cards. Memory
DIMM's should be selected to enable equal memory configurations across
processors in an n-way unit. If memory greater than the minimum is ordered,
the selection of memory features should be based on driving the most
number of DIMM quads onto the system, as evenly distributed across the
processors as possible.
#4492 8GB Dimms: The 8GB DIMM's carry the following restrictions:
– 8GB Dimms cannot be placed on a processor card with another size
DIMM
– 8GB Dimms slow the system memory clock down from 266MHz to 200
MHz
As a result, #4492 can only be placed on a processor card by itself, with
another #4492, or with a #7935.
Processor additions / Enclosure additions: Existing memory should be
spread onto the new processor cards or the additional processors should ship
with memory.
Offering Minimum memory Orientation feature
code x quantity
1/2-way 2GB #4452 x1
2/4-way 4GB #4452 x 2
5/8-way 8GB #4452 x 4
9/12-way 12GB #4452 x 6
13/16-way 16GB #4452 x 8
