5486IOp.fm Draft Document for Review October 18, 2004
328 IBM Eserver i5 and iSeries System Handbook
PCI-X Expansion Unit, #0595/#5095 PCI-X Expansion Tower, #5094 PCI-X
Expansion Tower, #5294 1.8m I/O Tower, #8093/#8094 Optional 1.8 M I/O Rack,
and the #5075 PCI Expansion Tower when attached to these models.
The #9792 is a base feature used on Models 825, 870, and 890 when ordered
with the iSeries Enterprise Edition. The #9792 includes two #9726 server
memory features (must be ordered as a pair).
The feature numbers of the #2792 PCI Integrated xSeries Server memory cards
are:
#0426/#9726 - 512 MB server memory
#0427 - 1 GB server memory
The #2892 is supported on the Model 270, 800, and 810 system units, on the
#5075 PCI Expansion Tower when it is attached to the Model 270, and on all
towers attached to the Models 800 and 810.
The feature numbers of the #2892 PCI Integrated xSeries Server memory cards
are:
#0446 - 512 MB server memory
#0447 - 1 GB server memory
At least two memory cards in the xSeries IOP are required. Allowable main
storage increments in MB are:
1024
2048
3072
4096
The #2792 and #2892 include one embedded 100/10 Mbps Ethernet LAN
controller. The #2792 and #2892 support up to three, in any combination, of
these LAN IOA features:
#2744 PCI 100 Mbps Token Ring IOA (one #0223 required for each #2744)
#5700 PCI 1 Gbps Ethernet IOA (one #0226 required for each #5700)
#5701 PCI 1 Gbps Ethernet UTP IOA (one #0226 required for each #5701)
Native iSeries functions are not supported. The #2792/#2892 servers do not
support an external host LAN.
The #2792/#2892 requires two PCI card slots on the system or expansion tower
backplane. The card does not reduce a third slot to a short slot.
The #2792/#2892 ships with a keyboard or mouse splitter cable.
