Summary of earlier AS/400, AS/400e, and iSeries models 833
Draft Document for Review October 18, 2004 5486MSum.fm
13.Maximums are:
12 of #6500
20 of #6501
9 of #6502, #6512, #6530, #6532, #6533
These maximums may be limited when used in combination with other disk
controllers.
14.With V4R1, a maximum of two workstation controllers is supported.
15.The combined maximum of local and remote displays attached to ASCII and
Twinax is seven with V4R1 and 28 with V4R2 and V4R3.
16.The lower number is for the #2161 processor. The higher number is for
#2163, #2165, and #2166 processors.
17.If there is no workstation controller specified, the console must be specified
by #9721.
18.One line is used for Operations Console. The maximum is nine if there is a
Twinaxial System Console.
19.For systems shipped between October 1997 and February 1998, maximum
storage is 2048M.
21. The maximum reflects the usage of two slot wide IPCS. If using a three slot
wide IPCS, Integrated Netfinity Server, or Integrated xSeries Server, the
maximum is two.
22. The maximum reflects the usage of two slot wide IPCS. If using a three slot
wide IPCS, Integrated Netfinity Server, or Integrated xSeries Server, the
maximum is four.
23. Requires V4R2 or later.
24. On the 9401 Model 150, the processor is the same on both the Twinaxial and
Server Models, and therefore, the performance figures are the same.
25. The performance figures shown are for a “constrained” workload due to
memory and disk limitations on the 9401 Model 150. If these limitations are
lifted, the “unconstrained” CPW measurements in the following table apply.
26. The system also includes a CD-ROM for IBM software.
Processor Interactive Client/server
#0591 and #0593 13.8 27.0
#0592 and #0592 20.6 35.0
