4 - 6
This command is for proceeding to Test Operation mode from Test Definition
mode.
When Test Definition is not completed or inconsistencies are detected in Test
Definition, the system cannot proceed to Test Operation mode.
This command is for proceeding to Test Definition mode from Test Operation
mode.
In case of aborting the test, Operation Status, Continuous Excitation Data, Graph
This command is for starting the excitation or the acquisition operation.
(SINE, RANDOM, CAPTURE)
In case of SHOCK, the action executed by this commend is decided according to
the status.
Waiting for the XFR Measurement start : XFR function is to be measured.
Drive Generation : Drive waveform data is generated from the reference data
and Inverse XFR function.
Waiting for Excitation Start : Excitationnoperation is to be started.
When the test operation is stopped by the command of user or by detecting abnormal
phenomenon, the button of [Retry] is set to valid.
This command is for proceeding to the waiting state for excitation /capture start by
pressing this button after the test operation is stopped.
This command is for stopping of the test in operation.
This command is for pausing of the test in operation without the excitation.
This command is for canceling the paused state and continuing the excitation.
This Command is for operating Sensitivity Calibration of a pickup during the
operation of a manual test. (Available only in SINE.)
