1–10
Transpector CPM Operating Manual
1.6.2 Weight
The approximate weight of Transpector CPM (without the Foreline Pump and the
CPM controller) is 15.5 kg (34 lb.).
NOTE: This weight does not include connecting cables.
1.6.3 Ventilation Requirements
For adequate ventilation, maintain at least 25.4 mm (1 in.)
clearance around the Transpector electronics module,
the CPM heaters and the pumping system.
If enclosing Transpector CPM, the enclosure must be large enough or ventilated to
provide adequate cooling airflow to the fan on the Transpector CPM pumping
system and the fan in the Transpector CPM controller.
1.7 Electrical Power Requirements
The CPM system components that require AC power input are:
CPM controller . . . . . . . . . . . . . . . . . Universal input, any voltage in the range
specified in section 1.7.1.1 is acceptable.
Personal computer . . . . . . . . . . . . . . Universal input, any voltage in the range
specified in section 1.7.1.1 is acceptable.
1.7.1 Required Supply Voltage
Except for the AC power input, the CPM controller supplies all required voltages.
1.7.1.1 Acceptable Supply Voltage Range
The AC power input must be 100, 120, or 230 V
~, ±10%
NOTE: If the input power is less than 100 V
~, the time required for the heaters to
reach their nominal temperature will be increased.
1.7.1.2 Required Frequency
50 or 60 Hz, ±5%
1.7.1.3 Power Rating
CPM controller—500 VA
