Transpector CPM Operating Manual
7.6.3 Procedure
CAUTION
Wear safety glasses and latex gloves during this
procedure.
1 Using two 9/16 in. open-end wrenches, remove the interstage tubing between
the two pump heads. (See Figure 7-2.)
Figure 7-2 Removing the interstage tubing
2 Using a #1 Phillips screw driver, remove the cam cover from the top side of the
foreline pump. (See Figure 7-3.)
Figure 7-3 Removing the cam cover
Interstage
Tubing
Cam Cover
