Inficon Transpector CPM - Hex Block Orifice Sampling Inlets

1–7
Transpector CPM Operating Manual
1.5.2 Hex Block Orifice Sampling Inlets
Table 1-2 HexBlock inlets and available orifices (maximum nominal pressure for orifice)
Inlet Orifices
V1 (LP) 3 mTorr (no orifice)
10 mTorr
15 mTorr
100 mTorr
360 mTorr
1 Torr
V2 (HP) 3 mTorr (no orifice)
10 mTorr
15 mTorr
100 mTorr
360 mTorr
1 Torr (bypass)
3 Torr (bypass)
10 Torr (bypass)
30 Torr (bypass)
1 Torr Sniffer (bypass)
3 Torr Sniffer (bypass)
7 Torr Sniffer (bypass)
10 Torr Sniffer (bypass
30 Torr Sniffer (bypass)
100 Torr Sniffer (bypass)
V3 (HC) 1 mTorr (High Conductance)
