Insightec Exablate 2100V1 - Thermal Dose Verification (Treat Mode)

TREATMENT STAGE
Manual Part Number
123
● This is effectively the beginning of the treatment. Select the spot parameters as
though you are beginning a treatment.
[W-32]
NOTE
◼ If the spot appears red, it is invalid and cannot be sonicated.
◼ If the spot appears yellow, be cautious. Try to optimize the location and/or the
sonication’s parameters.
[N-37]
7.4.4. Thermal Dose Verification (Treat Mode)
Thermal Dose Verification is used to confirm the tissue response is as expected at therapeutic level
energies.
Since different prostates might have different heating characteristics, you may need to adjust
the sonication energy level for each patient. This adjustment ensures that the sonication’s predicted
thermal dose will match the measured thermal dose.
Switch to Treat Mode.
NOTE
◼ The default scan orientation is OAx.
◼ Default Power for sonications is 30W.
[N-38]
1. Click this button and select Regular spot. Add the spot at the center of the ROT. Spots can be
added on the Current Anatomy strip only.
2. Follow the same monitoring guidelines as in the Geometric Verification Sonication Procedure.
