navigate through different slices, you can use the Up and Down arrows
buttons on the keyboard.
5.2.10. Image Overlays
5.2.10.1. Image Annotations
The image annotations consist of the orientations, patient details, scan parameters, scaling bar and image
type. MR magnitude images (Sonication Anatomy) consist of slice location while Temperature Maps consist
of the acquisition time.
5.2.10.2. Cursor Coordinates
The cursor coordinates show the location of the anatomical feature pointed in three axes on all image
windows.
Figure 5-3: Cursor Coordinates
