ADVANCED OPTION MODE
Manual Part Number
154
5. Select a MR Scanning Protocol:
◼ Select from the Thermal Mapping Protocol list in the pull-down menu.
◼ Create a new thermal mapping PSD. Type the new protocol name in the Protocol Name text box.
◼ The parameters of the selected protocol appear automatically. If a user protocol is created, manually
set all values for the protocol profile.
NOTE
Ensure that the user-defined protocol profile is correct and complete.
[N-2]
A.3.2. Profile Parameters Elements
◼ Type
Select the sequence type: Dual Echo, Single Echo or EPI.
◼ Phase Acquisition Time
The MR performs a single scan under the selected protocol in this time span.
◼ Images per Phase
This sets the number of images created by the MR for each phase.
◼ Magnitude Image Index
Determines which image in a series is the magnitude image.
◼ Real Image Index
Determines which image in a series is the real image.
◼ Imaginary Image Index
Determines which image in a series is the imaginary image.
◼ T1 Magnitude Index
For dual echo sequences, determines which image in a series is the echo 1 magnitude image.
◼ Thickness
Determines the slice thickness.
◼ Spacing
For multi slices sequences, determines the slice spacing.
