EVALUATION STAGE
Manual Part Number
135
6. Click this tool to perform a T1w+C Axial Evaluation Scan (with contrast), covering the
range that is defined by the Scan Range Lines, and using the optimal Central Frequency value that
has been previously found (see Section 6.4.2).
7. On the MR console, subtract the no-contrast series from the contrast-enhanced series. To upload
the subtraction series to the Exablate Prostate workstation, follow the procedure describe in the
following section.
8.4. Manual Evaluation Scan Acquisition
This feature allows uploading manually-scanned post-treatment MR series into the console in order
to present the accumulated dose overlay and evaluate treatment effect.
1. To load a new series, click this tool.
2. While the MR console is in Idle status, select a series in the MR console browser by clicking it.
3. The MR series will be transferred to the operating console into the 3rd Image Strip.
8.5. Volume Measurement
1. To measure a volume on the post treatment images, use this tool. The measured areas will
be shown on each slice, and the total volume will be shown on the bottom right corner of the
Selected Image Window.
2. Click this tool to show or hide the volume measurement overlay.
NOTE
To review the post-treatment series in Replay mode, skip to the last sonication that was
performed.
[N-45]
8.6. Exit Evaluation Stage
Click this tool to exit Evaluation Stage and terminate the treatment.
