SYSTEM OVERVIEW
Manual Part Number
21
1.4.3. Equipment Cabinet
The Equipment Cabinet (Figure 1-7), installed in the equipment room of the MR suite, houses the electronics
and amplifiers required for powering the system, along with the Control Personal Computer (CPC). It
includes the electronic interface to the patient’s bed, to the MR scanner and to the operators' workstation,
as well as the safety monitoring function of the system. The CPC coordinates the transducer power output
and focusing and controls its mechanical motion and electrical steering.
CAUTION:
Do not interact with the equipment cabinet. Only authorized INSIGHTEC service personnel
are qualified to operate this unit.
[C-1]
Figure 1-7: Exablate Prostate Equipment Cabinet
