PLANNING STAGE
Manual Part Number
72
The rest of tasks and features are considered as optional:
1. Define sensitive areas that will limit or eliminate the acoustic energy adjacent to them, by drawing
the Urethra, Nerve Bundles, Sphincter and Bladder (optional).
2. Define the required Treatment Protocol (optional).
3. Transfer the accumulated dose to newly scanned Planning images (in case of large movement).
Figure 6-1: Planning Screen
6.2. Planning Stage General Action Elements
During the Planning stage, the following new general Action elements are used (see Chapter 5 for an
explanation of the Imaging tools previously used).
Delete Selected
Object
Click this button to remove the selected object.
Delete All Objects
Click this button to remove all objects of the same type as the
selected object.
