TREATMENT TOOLS
Manual Part Number
Click this button to show or hide the drawn Rectal Wall contours.
Click this button to show or hide the Balloon Boundaries.
Low Energy
Density Regions
(LEDR)
Click this button to show or hide the Low Energy Density Region (LEDR)
overlays (urethra, nerve bundles, sphincter, and bladder).
Click this button to display the locations of the MR thermal slices on
the selected image window and on the image strips. The lines display
the intersection between the planned images and the thermal scan
images for selected sonication spots.
Click this button to select sonication spots display (Show/Hide all
spots).
Click this button to show or hide the accumulated dose. The
accumulated dose appears as a blue overlay on the image. In the
Thermal Evaluation screen, the dose from the last sonication is
displayed in green.
5.2.9. Navigation Tools
Navigation tools are used to select the content of the image strips which will be displayed, and to scroll
within the strips.
Click this button to select the images in one of the three image strip
windows to be displayed from the pull-down menu. Options may vary
between stages depending on the data available.
Use this button to scroll through an image series. The single arrows
scroll single images, and the double arrows scroll to the first or last
image. Alternatively, use the scroll bar under the image strips. To
navigate through an image series, you can use the Right and Left
arrows buttons on the keyboard.
Temperature Maps
Scroll Buttons
For multi-slice thermal scans, use this button to scroll between
different slices of the temperature maps in the selected image
window. Alternatively, select the desired slice in the image strips. To
