TREATMENT STAGE
Manual Part Number
◼ If they match, click Continue to accept the Thermal outcome and return to the
Treatment Main Screen (see Figure 7-1).
◼ If they do not match, click this button to adjust the thermal dose:
● A white contoured thermal dose prediction is displayed in the Selected Image window.
● Click and drag the mouse to change the white prediction size until it accurately overlaps the
measured thermal dose.
● The Information Box shows the adjustment value (percentage).
● Click this button to exit the dose adjust mode.
● A message box prompts you to Apply or Reject the new dose adjustment value.
◼ If the temperature map still contains an erroneous thermal dose (caused by
residual artifacts or noise), click to define which regions should be considered
as dosed regions. See Section 7.3.2).
◼ The Dose Adjust value can also be seen and reset in the Treatment Main Screen,
under the Spot Parameters Frame.
[N-39]
Do not perform an adjustment unless you can clearly discern the temperature rise. Failure
to do so may increase the risk of unintentionally treating non-targeted tissue.
[W-3]
10. Click Continue to accept the Thermal outcome and return to the Treatment Main
Screen (see Figure 7-1).
11. System will detect and notify about movements on the next slice, according to the Treatment
Direction defined in the Treatment Protocol.
