Chapter 8 Advanced 140
Example of configuring the speed test
Assume that a CPE working in AP mode (CPE1) and another CPE working in client mode (CPE2)
have bridged successfully. Then test the wireless speed between them.
The procedure can be performed both on the web UI of the CPE1 or CPE2. The CPE2 is used
for illustration here.
Assume that:
The IP address of CPE1 is 192.168.2.1, and both the login user name and password are
admin.
Configuration procedure:
1. Log in to the web UI of CPE2, and choose Advanced > Diagnose to enter the configuration
page.
2. Set Diagnose to Speed Test.
3. Set IP Address of Peer AP to Manual.
4. Enter the IP address of CPE1 to the IP Address box, which is 192.168.2.1 in this example.
5. Enter the login user name and password of the web UI of CPE1 in the User name and
Password boxes, which are both admin in this example.
6. Set Direction to Bidirectional.
7. Click Start.
It specifies the number of test connection launched by the client.
It specifies the test speed direction.
−
RX (Receive): only test the speed that the peer device transmits data to this
device.
−
TX (Transmit): only test the speed that this device transmits data to peer
device.
−
Bidirectional: test both transmit and receive speed between the two CPEs
It specifies the period of speed test.
It displays the average received rate.
It displays the average transmitted rate.
It displays the average total rate.
