Chapter 1 Application scenario 1
1 Application scenario
1.1 ISP hotspot connection-WISP mode
The internet access in an apartment needs to be achieved by connecting an ISP (Internet
Server Provider) hotspot.
1.1.1 Solution
IP-COM CPE can meet this demand.
CPE6S is used as an example to illustrate the installation procedures. Procedures for other
CPEs are similar.
Tip
To establish the network quickly, you are recommended to set up the CPEs before installing them.
1.1.2 Set up the CPE
1. Power on the CPE (powered by PoE in this example).
(1) Uncover the housing of the CPE.
(2) Use an Ethernet cable (CAT5e or better is recommended) to connect the PoE/LAN port of
the CPE to the PoE port of the PoE injector.
(3) Use the included power adapter to connect the PoE injector to a power socket. The Power
LED indicator of the CPE lights up.
PoE
CPE
Power socket
