Chapter 3 Web UI 21
3 Web UI
3.1 Web UI layout
The web UI of the CPE is composed of 4 parts, including the level-1 navigation tree, level-2
navigation tree, tab page area, and configuration area.
No.
Name
Description
❶
Level-1 navigation tree
The navigation bars and tab pages display the function menu of
the CPE. When you select a function in navigation bar, the
configuration of the function appears in the configuration area.
❷
Level-2 navigation tree
❸
Tab page area
❹
Configuration area
It enables you to view and modify configuration.
1
2
4
3
