Chapter 6 Network 84
Parameters description
It specifies the MAC address of LAN port.
It specifies the type of obtaining an IP address. The default is Static IP Address.
−
Static IP Address: Specify the IP address, subnet mask, default gateway,
and DNS server IP addresses manually.
−
DHCP (Dynamic IP Address): The device obtains an IP address, subnet
mask, default gateway and DNS server IP address from the DHCP server in
the network.
If the IP Address Type is set to DHCP (Dynamic IP Address), you need to check
the device’s IP address on the clients list of the DHCP server in the network, and
use this IP address to log in to the web UI of the device.
It specifies the IP address of the device. A LAN user can visit this address to enter
the web UI of the device. The default is 192.168.2.1.
To access the internet, change this IP address to the same network segment of
the LAN IP address of the egress router.
It specifies the subnet mask of the device. The default is 255.255.255.0.
It specifies the default gateway of the device.
You can set it to the IP address of the egress router to enable the device to access
the internet.
It specifies the primary DNS server IP address of the device.
If the egress router has the DNS agency function, it can be set to the LAN IP
address the egress router. Otherwise, specify a DNS server IP address manually.
If there is only one DNS server IP address, enter it in this box.
It specifies the secondary DNS server IP address of the device.
If there are two DNS server IP addresses, enter one in this box.
It specifies the name of the device. The default name indicates the product model
and version.
You are recommended to change the name to indicate the location of the device,
so that you can easily identify the device when there are multiple devices in the
network.
