JR XG 14 User Manual

60
▋▋For▋Airplane
Channel name Items which can be Included
Ch1: Throttle (THRO)
Ch2: Aileron (AILE)
Ch3: Elevator (ELEV)
Ch4: Rudder (RUDD)
Ch5: Gear (GEAR)
Ch6: Flap (FLAP)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
ETC: FPRN
If the Wing type is selected as “DUAL ELEV” or “4-AILE”or “6-AILE” it is possible
to arrange mixing on Aileron as a ap.
AILV
If the Wing type is selected as “DUAL ELEVE” or “4-ELEV”,it is possible to arrange
mixing on elevator as an Aileron movement. And it is also possible to include
Aileron di󱐯erential.
RDVT
When the Wing type is set to “DUAL RUDD” it is possible to mix to the elevator
from Rudder.
FLAI
When the Wing type is set to “DUAL FLAP”, it is possible to mix to the Aileron
from Flap. And it is also possible to include Flap Di󱐯erential (FLAP DIFF.) in the
mix.
▋▋For▋Glider
Channel name Items which can be Included
Ch1: Flaperon (FPRN)
Ch2: Aileron (AILE)
Ch3: Elevator (ELEV)
Ch4: Rudder (RUDD)
Ch5: Gear (GEAR)
Ch6: Flap (FLAP)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
ETC: AILV
When the Wing type is set to “DUAL ELEV” (Dual Elevator) it is possible to mix to
Aileron from Elevator. And it is also possible to include Aileron Di󱐯erential (AILE
DIFF.) in the mix.
RDVT
When the Wing type is set to “DUAL RUDD” it is possible to mix to Elevator from
Rudder.
FLAI
When the Wing type is set to “DUAL FLAP” (Dual Flap) it is possible to mix to
Aileron to the Flap And it is also possible to include Flap Differential (FLAP
DIFF.) in the mix.
SPRD
When the Wing type is set to “DUAL SPOI” it is possible to mix to Rudder from
Spoiler.
MOTO
It is possible to mix to the available Channel from the allocated channel for
Motor control.
▋▋Caution▋Note
⿟ Actually operate the servos and carefully conrm the settings before ying.
