59
▋▋For▋Glider
Channel name Items which can be Included
Ch1: Flaperon (FPRN)
Flaperon Mixing (FPRN MIX), Camber System(CAMB SYS), Brake system (BRAKE
SYS), Elevator=>Flap MIX(ELEV->FLAP), Flap Rate (FLAP RATE)
Ch2: Aileron (AILE) Aileron Trim, Dual Rate (D/R&EXP), Camber system (CAMB SYS)
Ch3: Elevator (ELEV)
Trim, Dual Rate (D/R&EXP), Flaperon Mixing (FPRNMIX), Brake System
(BRAKESYS)
Ch4: Rudder (RUDD) Trim, Dual Rate (D/R&EXP), AILE → RUDD (Aileron → Rudder Mixing)
Ch5: Gear (GEAR)
Ch6: Flap (FLAP)
Trim, Flaperon Mixing (FPRN MIX), Brake System (BRAKE SYS), Elevator =>Flap
Mixing (ELEV → FLAP MIX)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
Extra: #SPO Mixing from the Spoiler Stick.
FMOD The mixing can be coupled to the Flight Mode Switch.
TRNR The mixing can be coupled to the Trainer switch.
MOTO Channel which is allocated for Motor control.
▋▋Slave▋channel’s▋name,▋application▋items▋which▋can▋be▋“INCLUDED”
▋▋For▋Helicopter
Channel name Items which can be Included
Ch1: Throttle (THRO)
Ch2: Aileron (AILE)
Ch3: Elevator (ELEV)
Ch4: Rudder (RUDD)
Ch5: Gear (GEAR)
Ch6: Pitch (PIT.)
Ch7: AUX2
Ch8: AUX3
Ch9: AUX4
Ch10: AUX5
Ch11: AUX6
Ch12: AUX7
Ch13: AUX8
Ch14: AUX9
ETC: CH2 When this Swash Type is set, it provides mixing to Channel 2.
CH3 When this Swash Type is set, it provides mixing to Channel 3.
CH6 When this Swash Type is set, it provides mixing to Channel 6.
CH8 When this Swash Type is set, it provides mixing to Channel 8.
NEDL It is possible to set Mixing to the Needle channel.
